IT-VE-60-E1YN

V60E

Antenne maritime VSAT Ref : IT-VE-60-E1YN

Système VSAT maritime en bande Ku de 65 cm

PRIX : NC

Descriptif

SUPERIOR RF PERFORMANCE

The v60E is a lightweight and affordable Ku-band stabilized VSAT maritime antenna system designed for entry into new market sectors and to increase the competitive edge in the 65cm class. The v60E's RF design delivers higher levels of performance, with a standard 6W BUC and Cross-pol only configuration, at significantly reduced pricing, providing customers with lower budget access to the quality and reliability of an Intellian product.

Compact and Lightweight

Reduces freight and installation costs thereby lowering the total cost of ownership.

  • Ideal for smaller vessels which have limited space for a larger system
  • Compact package reduces freight and deployment costs
  • Overall lower total cost of ownership

Antenna Management Platform

Intellian's integrated Aptus platform, provides a responsive web user interface to manage and control the antenna system.

Intelsat Flex Certified

The v60E ensures access to high-throughput satellite networks

Quick and Easy Installation

  • Single Cable connection
  • Pre-slung lifting straps
  • Aptus step by step installation wizard to guide easy installation

Caractéristiques

Radome Dimension : 86x93.5 cm (33.85x36.8 inch)
Reflector Diameter : 65cm (25.6inch)
Antenna Weight : 42kg/ 92.6 lbs
TX Frequency : 13.75~14.5GHz Ku-band
RX Frequency : 10.7~12.75GHz Ku-band
TX Gain : 37.9 dBi @ 14.25 GHz (excl. radome)
RX Gain : 36.5 dBi @ 11.7 GHz (excl.radome)
G/T : 15.5 dB/K (min.)
